Floor 2 Correlation
Input
Output
No in-suite
signal silence
Floor 2 dwelling and hallway inputs
Floor 2 dwelling and hallway audibles
Floor 3 Correlation
Input
Output
No in-suite
signal silence
Floor 3 dwelling and hallway inputs
Floor 3 dwelling and hallway audibles
Floor 4 Correlation
Input
Output
No in-suite
signal silence
Floor 4 dwelling and hallway inputs
Floor 4 dwelling and hallway audibles
Floor 5 Correlation
Input
Output
No in-suite
signal silence
Floor 5 dwelling and
hallway inputs Floor 5 dwelling and hallway audibles
Creating a hallway correlation
The hallway correlation ensures that an alarm detected anywhere in the building will turn on all
audibles located in hallways throughout the building.
On the input side of this correlation, add all input devices on all floors. Include all those inside
dwelling units and all those in hallways.
On the output side, add all hallway sounders throughout the building.
Notes
• Set the alarm activation count for this correlation to 1.
• Do not enable in-suite signal silence.
Hallway Correlation
Input
Output
Occupant and hallway inputs on all floors
Hallway sounders on all floors
Creating an in-suite correlation group
The in-suite correlation is used to silence sounders inside dwelling units, except on the floor of
alarm.
Create one in-suite correlation group. On the input side, add all input devices on all floors.
Include those located inside dwelling units and those located in hallways.
On the output side, add all sounders located inside dwelling units on all floors.
