EN UG-020 Link 6 user guide r1.0 134
Virtual controls in Cartesian Hand Guiding mode
Virtual controls in angular Manual Jog mode
Tip: The controls are available only
when the enabling device is held in the
center position.
Tip: Tap the up arrow ( ) in the corner
to expand the view of the controls.
Tip: Tap the down arrow ( ) in the
corner to collapse the view of the
controls.
Virtual controls in Cartesian Manual Jog mode
Tip: The controls are available only
when the enabling device Is held in the
center position.
Tip: Tap the up arrow ( ) in the corner
to expand the view of the controls.
Tip: Tap the down arrow ( ) in the
corner to collapse the view of the
controls.
