EN UG-020 Link 6 user guide r1.0 88
Safety parameter Description
SF06 Protection zone monitoring
Position of all configured protection zones
Shape type (sphere, cylinder, rectangular
prism)
Dimensions of all configured protection
zones
Orientation of all cylindrical and prismatic
protection zones
Activation status: enabled or disabled
Tool Sphere
Position (X,Y,Z)
Dimension
SF07 Safety TCP monitoring
Translation speed normal speed mode limit
Orientation speed normal speed mode limit
Translation speed reduced speed mode limit
Orientation speed reduced speed mode limit
Safety Elbow monitoring
Translation speed normal speed mode limit
Translation speed reduced speed mode limit
Arm calibration
Microscopic assembly defects are compensated by the firmware of the robot when the arm is
calibrated.
The calibration package contains the default calibration file associated with the serial number
found on the arm, its checksum, and the serial number of the arm.
The calibration file contains a few vital pieces of information.
Calibration date
Serial number of the arm
Geometric calibration parameters
Elasto-static calibration parameters
Access the status of the arm at Systems > Robot > Arm > Calibration.
