Kinova Link 6 - Wrist Power Supply; General-Purpose Inputs and Outputs for the Wrist; Wrist RS-485

EN UG-020 Link 6 user guide r1.0 44
Connector A Connector B
Pin # Label Purpose Label Purpose
5 +24v Power +24v Power
6 DIGITAL_IO3 Digital In/Out DIGITIAL_IO7 Digital In/Out
7 DIGITAL_IO4 Digital In/Out DIGITIAL_IO8 Digital In/Out
8 GND Ground GND Ground
Wrist power supply
The maximum current is shared among all power outputs of the wrist, including the A and B
connectors and the pogo pad.
The wrist can handle a maximum of 5 A among all connection points. If one M8 connector is
using 1 A, there is only 4 A left for the other interfaces.
Important: The maximum current that can be used by any one M8 connector is 1.4 A.
General-purpose inputs and outputs for the wrist
Unless otherwise specified, all general-purpose digital and analog inputs and outputs have the
same specifications as the Industrial I/Os.
Related topics
General-purpose digital inputs on page 35
General-purpose digital outputs on page 36
Analog inputs on page 38
Analog outputs on page 38
Wrist RS-485
RS-485 on the wrist is used only for Modbus RTU when it is exposed through EIA/TIA-485-A,
commonly referred to as RS-485.
Important: There is no RS-485 communication available from KortexWebApp.
Table 33: RS-485 pins on the wrist
Label Purpose
RS_485_P RS-485 D+ (B)
RS_485_N RS-485 D- (A)
GND RS-485 SC (G)
Table 34: RS-485 power inputs
RS-485 Min Typical Max Unit
Input voltage at A/B terminal -7 5 12 V
Current 2 A
