(1) Hand Throttle Lever
: Fast : Slow
M55O547A
M55O4R3A
(1) Position Control Lever (2) Bolt
(A) Lifting (B) Lowing
5. Lower the attachment by pushing
the position control lever foward.
(1) Forward / Reverse Lever
(2) Main Shift Lever
(3) Range Shift Lever (4) P.T.O Switch
M55O554A
3. Place the PTO switch to the "OFF"
position. (It cannot be started while
the PTO is engaged)
4. Set the main, range and shuttle
shift levers in the neutral position.
Make sure that no one is near
the implement or behind the
tractor.
WARNING
7. Set the hand throttle lever to the
"Slow" position. (In case of cold
weather you may adjust it to "Fast"
for easier starting)
8. Depress the clutch pedal. (It can
-
not be started when the clutch is
not depressed)
To Next Page
