SEAT BACK RECLINING
(1) Seat Back Adjustment Lever
M55O4M5A
(1) Seat Adjustment Lever
M55O4M4A
SEAT ADJUSTMENT
SEAT SLIDING
To change the seat back angle, raise
the lever (1) on the left of the seat.
Then, adjust the seat back angle
with the lever pulled. Release the le-
ver after adjustment. Make sure that
the lever is returned and the seat is
rmly xed after adjustment.
Do not put a hand between the
seat and the slides when ad-
justing the seat position. You
can get injured unexpectedly.
•
CAUTION
To adjust the seat position, pull the
lever (1) to upward under the front of
the seat, slide the seat to the desired
position, and then release the lever.
Make sure that the seat is rmly xed
by moving it gently after adjustment.
The seat height can be adjusted to
fit to the driver. Turning the handle
(1) on the front of the seat clockwise
raises the seat while turning it coun-
terclockwise lowers the seat.
(1) Seat Height Adjustment Handle
M55O4M6A
SEAT HEIGHT ADJUSTMENT
