MAINTENANCE
7
Apply high-quality multi-purpose grease onto the positions in the gure at every 100 hours of operation or whenever
necessary.
LUBRICATING GREASE LOCATIONS (P)
(1) Front axle support bracket (FRT)
(2) Front axle case support (LH)
(1) Front axle support bracket (RR)
(2) Front axle case support (RH)
(1) Brake shaft (RH)
M55O766A M55O7B3A M55O7B4A
(1) Brake shaft (LH)
M55O771B M55O772B
(1) Pitman arm support
M55O7B5A
(1) Hydraulic cylinder (upper/lower)
(2) Top link (upper/lower) (3) Lift rod (LH/RH)
