(1) Double Acting Valve Lever 1
(A) Port A (B) Port B
M55O4P2A
If the lifting arm is properly
operated but abnormal noise
is still heard, the hydraulic sys-
tem may be malfunctioning. In
this case, let the engine idle for
an 10 to 15 minutes addition-
allly and then try to start the
engine again. If the problem is
still present, contact your local
KIOTI Dealer.
7. However, if the draft control lever is
pushed forward to its end, the low-
est position of the lifting arm can be
lowered a little. On the other hand,
if the lever is pulled back to its end,
the highest position of the lifting
arm can be raised a little.
CAUTION
The implement may shake up
and down as the draft sensor
is under impact when the trac-
tor is passing over irregular
ground with the middle or low-
est top link hole selected. In
this case, put the draft control
lever to the "Deep" position
to decrease the sensitivity of
the draft function or select the
highest top link hole.
If the tractor has been stored
for a long period of time or
the transmission fluid is just
changed, abnormal noise may
be heard and the hydraulic
lifting arm may be inoperable
temporarily. In this case, let the
engine idle for 3 to 4 minutes.
CAUTION
REMOTE HYDRAULICS
DOUBLE ACTING VALVE
