Kioti RX6010C - General Specifications; External Dimensions

3
-
2
RX6010C / RX6010PC
※These dimensions are measured with standard tires (AG) installed on the CABIN model tractor.
in. (mm)
A1
A2
A3
D
D47O301a
※ A1: Overall length including weights
A2: Overall length excluding weights
A3: Overall length including weight support
E1: Front wheel tread E2: Rear wheel tread
ITEM RX6010C / RX6010PC REMARK
1. Overall length (A1)
158.3 (4,020)
2. Overall length (A2)
145.7 (3,700)
3. Overall width (B)
69.1 (1,755): USA
73.8 (1,875): AU/EU
4. Overall height (C)
102.8 (2,610): USA
103.5 (2,630): AU/EU
5. Wheel base (D)
82.7 (2,100)
6. Tread (E1)
54.1 (1,375): USA
58.1 (1,475): AU/EU
7. Tread (E2)
54.1 (1,375): USA
58.7 (1,490): AU/EU
8. Ground clearance (F)
16.5 (420)
GENERAL SPECIFICATIONS
EXTERNAL DIMENSIONS
