MAIN FUSE (AS)
(1) Ignition Power Fuse (2) Preheat Power Fuse
(3) Main Power Fuse (4) Charge Power Fuse
M55O7A5A
The main fuse is to protect electric devices and wirings. If the ignition, pre-
heat, charge or main function is faulty, nd and remove the fault and replace
the fuse with a new one.
Main Fuse 60A
Using a non-approved slow-blow fuse can damage electrical sys-
tems in the tractor severely.
Refer to the chapter "Troubleshooting" in this manual or contact
your local KIOTI Dealer for specic information dealing with electri-
cal problems.
•
•
IMPORTANT
The bulb and capacity used in this
tractor are listed in the below table.
REPLACING BULB (AQ)
No. Bulb Capacity
1 Head Lamp 55W/55W
2 Position Lamp (Front) 5W
3 Stop/position Lamp (Rear) 21W/5W
4 Turn Signal Lamp 21W
5 Work Lamp 35W
6
Cluster
Indicator
Charging
Warning Light
3W
Others 1.4W
7 Backup Lamp 21W
