REMOVAL AND INSTALLATION OF 3-POINT HITCH IMPLEMENT (WITH PTO SHAFT)
1. Drive the tractor backward to move
close to an implement (approx. 5
cm). Then, adjust the height of the
lower link to be parallel to the pins
of the implement.
2. Put all the shift levers in the neu-
tral position, stop the engine, and
apply the parking brake.
H11O562A
(1) Implement Support (1) Telescopic Stabilizers Pin
H11O567A
3. Remove both of the Telescopic
Stabilizers xing pins.
When removing/installing an
implement, remove the check
link pin to use the lower link
end (cassette type) effectively.
(1) Latch (2) Lower Link End
H11O564A
4. Press the latch to pull out the low-
er link end. (Cassette type)
IMPORTANT
To Next Page
