7. The lower limit of the implement’
s height can be set by limiting the
movement of the control lever us-
ing the stop bolt.
If trying to lift an object with
e x c e s s i v e w e i g h t b y t h e
3-point hitch while the tractor
is not equipped with proper
front suit case weights, the
fro nt wheels may be l ift ed
instead, leading to roll over.
Make sure to follow the speci-
cations for use.
WARNING
M55O4R3A
(1) Position Control Lever (2) Bolt
(A) Lifting (B) Lowing
(1) Lowering Speed Control Knob
(A) High Speed (B) Low Speed
M55O560A
6. The lowering speed of the lower
link is proportional to the applied
weight but can be controlled by ad-
justing the draining passage of the
hydraulic fluid. (See "Lifting arm
speed control knob" on Page 4-32)
To Next Page
