8.1.5 Control Signals (Control Bits)
The functions of the control bits on the fieldbus correspond to those of the digital input and
output signals of the interface X2 Dig-IO, where present.
Control signals - input control bits
Bytes 0 … 13 of the telegram
maXYmos BL IN
PROFIBUS EtherNet/IP PROFINET CC-Link
B
y
te
[Dec]
Bi
t
[Dec]
Position
[Hex]
Description Description
0
0 RY00 START Cycle START
1 RY01 TARE-Y TARE-Y or reset piezo
2 RY02 ZERO-X Zero channel X
3 RY03 TEST-X Trigger test for sensor for channel X
4 RY04 TEST-Y Trigger test for sensor for channel Y
5 RY05 Reserved
6 RY06 Reserved
7 RY07 Reserved
1
0 RY08 Reserved
1 RY09 ACK-ADMIN
Acknowledgement with Administrator rights (e.g. regarding
corresponding warnings or alarms)
2 RY0A Reserved
3 RY0B ACCESS
Allows the PLC to grant the user access rights. The object
protectionPlcLogon is used to set which group of rights
(Setter, Operator or Administrator) is active.
If ACCESS = 1 the user can use these rights (does not have
to log on separately), ACCESS = 0 corresponds to a logoff.
4 RY0C AUTO
The AUTO bit must be set (byte 1.4 = 1) if the measuring
program is to be switched by means of the PLC fieldbus.
With AUTO=1 the PLC has full control over the maXYmos.
This also blocks setting up manually!
5 RY0D STAT-RESET Reset statistics
6 RY0E STAT-DISABLE Disable statistics
7 RY0F Reserved
2
0 RY10 MP-0 [1]
Measuring bit selection (see also byte 14: Page control input
control/config bits).
1 RY11 MP-1 [2]
2 RY12 MP-2 [4]
3 RY13 MP-3 [8]
4 RY14 Reserved
5 RY15 Reserved
6 RY16
Reserved
7 RY17
Reserved
