Kistler maXYmos BL - Examples of START-STOP Combinations

maXYmos BL, Type 5867B…
Page 40 5867B_002-626e-04.16
4.3.5.4.5 Examples of START-STOP Combinations
X
Y
START
DIG-IN
STOP
Thresh-Y
I-START
X
Y
START
DIG-IN
I-START
I-START must not be
taken to 0 until the
STOP-Thresh-Y has
been reached.
Otherwise the cycle
would be prematurely
interrupted with the
falling edge of I-
START!
If this is not possible,
the termination of the
cycle can be
prevented by turning
on (the checkbox)
"Ignore Stop Dig In".
STOP Thresh-X, from RIGHT
X
Y
START Thresh-X, from LEFT
X
Y
START
Thresh-X
STOP
Thresh-Y
X
Y
STOP
DIG-Input
STOP
DIG-Input
I-START
STOP
Return-X
e.g. 8 mm
X
Y
START
Thresh-X
