maXYmos BL, Type 5867B…
Page 34 5867B_002-626e-04.16
4.3.5.2 Choosing GLOBAL or MP-specific Cycle Control
The checkbox "Use Settings from GLOBAL SETUP" in the MP Setup is used to decide
whether the parameters of Cycle Control are to be configured and used GLOBALLY or MP-
specific.
An MP-specific setup of cycle control can be necessary when, for example:
1. The measurement curve of Part1 is to be captured using Y=f(X) and of Part 2 using
Y=f(t)
2. The return is to be shown for Part3 and cut off (truncated) for Part4
3. The START conditions are different (Part 5: short displacement, Part 5: long
displacement)
This tick decides whe
her the
parameters for Cycle Control
are to be used GLOBALLY or
MP-specific. Default: GLOBAL.
