5.5.2 HTTP Port
It is used to connect to the DVR web server. By default the value of the port is 80. You can
specify a different port number.
5.5.3 Command Port
It is used to control the DVR. By default the value of the command port is 5050. You can
specify a different port number.
5.5.4 Media Port
This port is used for audio and video stream. By default the value of the media port is 6050.
You c an spe ci f y a di ff e re nt port number.
5.5.5 PPPoE Settings
The following settings are located on the second page of
the Net Tab. Press Next Page to open these options.
You c an a c t i v at e or d ea ct i v at e (ON/ OFF o p t i o n s ) PPPoE settings. The changes will
take effect after you save them.
HTTP port: 80, Command port: 5050, Media port: 6050 and
Mobile surveillance port: 7050 must be open/allowed to upload
to WAN interface if the DVR is behind a Firewall server.
If the DVR is installed behind a Router to share a single public
IP address, be sure to configure the “Port Forwarding” or
“Virtual Server” for those three network ports and the Mobile
surveillance Port: 7050.
