204
Edit menu
From any page, press the MENU button to open the Sound edit
menu. This menu gives access to the various Sound edit sections.
When in the menu, select an edit section, or press EXIT or
SOUND to exit the menu and return to the main page. To return
to the main page, you can also select the Main Page menu item.
When in an edit page, press EXIT or the SOUND button to
return to the main page of the Sound operating mode.
• When an ordinary Sound is selected:
• When a Drum Kit is selected, the “Basic” section is
replaced by the “DrumKit” section:
Each item in this menu corresponds to an edit section. Each edit
section groups various edit pages, that may be selected by touch-
ing the corresponding tab on the lower part of the display.
Edit page structure
All edit pages share some basic elements.
Operating mode
This indicates that the instrument is in Sound mode.
Edit section
This identifies the current edit section, corresponding to one of
the items of the edit menu (see “Edit menu” on page 204).
Page menu icon
Touch this icon to open the page menu (see “Page menu” on
page 227).
Selected oscillator
Use these buttons to select the oscillator to edit.
Parameters area
Each page contains various parameters. Use the tabs to select
one of the available pages. For detailed information on the vari-
ous types of parameters, see sections starting from page 204.
Tabs
Use tabs to select one of the edit pages of the current edit section.
Basic: Sound Basic
Here you can make basic settings for the Sound, such as basic
oscillator settings, the oscillator count, and the polyphonic
mode.
Operating mode Edit section
Selected
oscillator
Page menu
icon
Parame-
ters area
Tabs
