104
Selecting elements
Sound Select window
The following windows are shown in the various operating
modes, whenever you try to select a Sound, Performance, Style
or Song.
Sound Select window
Touch the Sound area whereas it appears in the display, or one of
the SOUND SELECT buttons in the REAL TIME TRACKS sec-
tion of the control panel to open the Sound Select window.
Press EXIT to exit from this page and go back to the previous
page without choosing any Sound.
Sound sets
Selected set of Sounds. Factory Sounds are the Sounds supplied
as standard. Legacy Sounds are Sounds compatible with older
Pa-Series models. GM2/XG DK are Drum Kits mapped accord-
ing to the General MIDI 2 or XG standards. User Sounds are
custom-created or edited Sounds.
Side tabs (banks)
Use these tabs to select a bank of Sounds.
Lower tabs (pages)
Use these tabs to select one of the available pages in the selected
bank.
Previous/Next tabs
Scroll the lower tabs to the left or the right, when additional tabs
are available but cannot be seen in the display.
Sounds
Touch one of these buttons in the display to select a Sound.
Unless the “Display Hold” parameter (see page 207) is turned
on, the window automatically closes shortly after you select a
Sound.
Program Change
Program Change number. Shown only when the “Show” param-
eter is turned on in Global mode. (See page 206).
Performance Select window
Touch the Performance area whereas it appears in the display, or
one of the PERFORMANCE SELECT buttons on the control
panel, to open the Performance Select window. Use the PER-
FORMANCE SELECT buttons to go directly to the selected
bank.
Press EXIT to exit from this page and go back to the previous
page without selecting any Performance.
Note: Depending on the status of the “Auto Select” parameter (see
page 207), a Performance may be immediately selected when
pressing one of the PERFORMANCE SELECT buttons. The latest
selected Performance for that bank will be selected.
Side tabs (banks)
Use these tabs to select a bank of Performance. Each tab corre-
sponds to one of the PERFORMANCE SELECT buttons on the
control panel.
Lower tabs (pages)
Use these tabs to select one of the available pages in the selected
bank.
If you press again the same PERFORMANCE SELECT button
on the control panel, the next page in the same bank is selected.
This way, you do not need to touch one of the corresponding
tabs in the display in order to select a different page.
Performances
Touch one of these buttons in the display to select a Perfor-
mance. Unless the “Display Hold” parameter (see page 207) is
turned on, the window automatically closes shortly after you
select a Performance.
Selecting elements
Side tabs (banks)
Lower tabs (pages)
Type of Sound
Sounds
If more than four pages are available,
the Previous/Next tabs are shown in
this area
Side tabs (banks)
Lower tabs (pages)
Perfor-
mances
To Next Page
