Installing an Hard Disk (HDIK-2) (only 61-key model)
Formatting the Hard Disk and installing the Operating System
3. From the bottom of the instrument, remove the six fixing
screws (e) and the three flat head fixing screws (f), and keep
them apart. Open the cover (g) to gain access to the inside
of the video board compartment, and keep the cover apart.
4. Disconnect the USB key (h) from the cable (i), and remove
the board (h) by unscrewing the two fixing screws (j).
5. Place the previously assembled hard drive over the four ded-
icated spacers inside the instrument (the drive can only be
installed in a way). Fix it with the last four screws (c) found
in the installation kit. Connect the hard drive to the cable (i)
you previously disconnected from the USB key.
6. Place the cover (g) to close the instrument, being careful not
to damage the cable, by following in reversal the opening
instructions.
7. When the installation is finished, please connect the power
cord, and turn the instrument on again. You must now for-
mat the hard disk, before accessing it for data storage.
Formatting the Hard Disk and installing
the Operating System
When the installation is finished, you must format the hard
disk and install the operating system.
1. Copy the “Pa3X_RES.pkg” operating system file to the root
of an USB storage device. The file can be found on our web
site (www.korg.com
). Please note that the name of the file
should not be changed.
2. Connect the power cord and turn the instrument on by
pressing the POWER, then the STANDBY button.
3. After a few seconds, the “Touch Panel Calibration” page
appears. Execute the calibration of the display by following
the onscreen instructions, then confirm by touching the
Save button in the display.
