153
Song Play operating mode
Mixer/Tuning: EQ Control
Reference
Mid (Middle) Gain
This parameter lets you adjust the middle frequencies equaliza-
tion on each individual track. This is a bell curve filter. Values
are shown in decibels (dB).
-18…+18dB Middle gain value in decibels.
Low Gain
This parameter lets you adjust the low frequencies equalization
on each individual track. This is a shelving curve filter. Values
are shown in decibels (dB).
-18…+18dB Low gain value in decibels.
Play/Mute icon
Track’s play/mute status. See “Keyboard track status” on
page 145 for more information.
Play status. The track can be heard.
Mute status. The track cannot be heard.
Mixer/Tuning: EQ Control
This page lets you reset or bypass track equalization, pro-
grammed in the previous page.
Use the TRACK SELECT button to switch from the Keyboard to
the Song tracks, and vice-versa.
Track Reset buttons
Use these buttons to reset (i.e., “flatten”) equalization for the cor-
responding track.
Reset All Tracks button
Touch this button to reset (i.e., “flatten”) equalization for all
tracks (both Realtime and Song tracks).
Bypass
Check any of these checkboxes to bypass equalization for the
corresponding track. When bypassed, equalization has no effect
on the track, but all parameters are preserved. When the box is
unchecked, equalization is activated again with the original set-
tings.
On The bypass function is engaged, so no equaliza-
tion is active on the corresponding track.
Off The bypass function is not engaged, so the equal-
ization is active on the corresponding track.
To Next Page
