212
Global edit mode
MIDI: MIDI In Channels
MIDI: MIDI In Channels
In this page, you can assign Pa3X tracks to any of the MIDI
channels received on the MIDI IN and USB Device ports.
Channels
You can assign to each channel one of the following tracks:
Off No track assigned.
Lower Lower track.
Upper 1…3 One of the Upper tracks.
Pad 1…4 One of the Pad tracks.
Drum Drum track.
Percussion Percussion track.
Bass Bass track.
Acc 1…5 One of the Auto-accompaniment tracks.
Ply.1 Tr 01…16
One of Player 1 tracks.
Ply.2 Tr 01…16
One of Player 2 tracks.
Global Special channel to simulate the Pa3X’s integrated
controls (keyboard, pedals, joystick) with an
external keyboard or controller. MIDI messages
coming on this channel are seen as if they were
generated by Pa3X’s integrated controllers.
Control On this special channel, the Pa3X receives MIDI
messages to remotely select Styles, Performances,
STS, Style Elements and SongBook entries. See
tables on page 183 and following for more infor-
mation on the received data
MIDI: MIDI Out Channels
In this page, you can assign Pa3X tracks to any of the MIDI
channels sent to the MIDI OUT and USB Device ports.
Channels
You can assign to each channel one of the following tracks:
Off No track assigned.
Lower Lower track.
Upper 1…3 One of the Upper tracks.
Pad 1…4 One of the Pad tracks.
Drum Drum track.
Percussion Percussion track.
Bass Bass track.
Acc1…5 One of the Auto-accompaniment tracks.
Ply.1 Tr 01…16
One of Player 1 tracks.
Ply.2 Tr 01…16
One of Player 2 tracks.
Ply.1/2 Tr 01…16
Use these channels to send data generated by a
track with the same name on either or both
onboard players at the same time.
Chord Use this channel to send notes recognized by the
Chord Recognition engine to the MIDI OUT and
USB Device port. This is useful, for example, to
control an external Harmonizer from the Pa3X,
using the Lower track to play chords, even if the
track is muted.
