Krone Big M II User Manual

X - 10
Mowers
10.3 Maintenance ot the Mowers
The tool supplied can be kept in the storage compartment
(1).
8
.
8
1
0
.
9
A
KR-1-130
10.3.2 General
10.3.1 Special Safety Instructions
A
Ø
5.6 6.8 8.8 10.9 12.9
M
A
(Nm)
M
4 2,2 3,0 4,4 5,1
M
54,55,98,710
M
6 7,6 10 15 18
M
818253643
M
10 29 37 49 72 84
M
12 42 64 85 125 145
M
14 100 135 200 235
M
14x1,5 145 215 255
M
16 160 210 310 365
M
16x1,5 225 330 390
M
20 425 610 710
M
24 730 1050 1220
M
24x1,5 350
M
24x2 800 1150 1350
M
27 1100 1550 1800
M
27x1,5 850
M
27x2 1150 1650 1950
M
30 1450 2100 2450
 Maintenance, cleaning and repair work should be done only when the machine is at a
complete standstill.
 Shut down the engine and remove the ignition key.
 After completing maintenance work reattach all protective plates and protective devices
properly.
 Avoid skin contact with oil and grease.
 With injuries caused by oil escaping under pressure, get the assistance of a doctor
immediately.
 Follow all further safety instructions, to avoid accidents and injuries.
Regularly check that nuts and bolts are
tightly in place (approx. every 50 hours)
and tighten them if necessary.
Torque M
A
in Nm (unless otherwise stated).
A = thread size
(Resistance class is given on the bolt head)
