Kronos InTouch 9100 Standard - Example 2: Ethernet Cable

Step 4: Disconnect cables from the main board
129
Example 2: Ethernet cable
1. Loosen and then swivel the strain relief clip before you remove the cable.
2. Push in the top of the Ethernet connector clip and then pull out the cable.
Standard Model Slim Profile Model
