Chapter 3 Install the Slim Profile InTouch
72
Route the AC wall transformer cord
If the power source is from a wall transformer that will be plugged into a nearby
outlet, route the cable as shown. Note that the base must be within 5 feet of the
outlet.
Note: Do not plug in the power until you are instructed to do so.
