Appendix A Replace a Series 4000 Device with the InTouch
122
Step 3: Install and configure the InTouch
1. Install the InTouch, as described in this installation guide. Note the following:
– You can install the base of the InTouch in the same location as the Series
4000, but you must drill new screw holes into the wall.
– Although the InTouch can be installed in the same location as the Series
4000, the InTouch is a smaller unit. Therefore you may need to repaint
part of the wall or make similar modifications to hide areas of the wall
that were formerly covered by the Series 4000 unit.
– If you had used the direct AC wiring option for the Series 4000, you must
mount the InTouch over or near an outlet, or use Power-over-Ethernet
(PoE) or PoE Plus.
2. If you use bar code badges, send a sample of those badges to Kronos for
badge evaluation, to verify that your bar code badges will work with the
InTouch.
Note: The InTouch does not ship with Supervisor badges. You must either
purchase them separately or use the Manager Logon transaction in Manager
mode.
3. On the host application server, use the device management settings to copy
the Series 4000 configuration information and use it for the InTouch.
a. Create duplicates of the following building blocks from the 4500 model
and change the Model to InTouch: Device Communication settings,
General device settings, Soft key settings.
b. Assign those building blocks to the new device configuration profile for
InTouch.
c. Use Device Setup to assign the newly created device configuration profile
for InTouch to the installed InTouch device.
