Chapter 2 Install the Standard Model InTouch
36
Cable routing guidelines
Note: You must route these cables into the base before you attach the plastic
transformer holder or transition board to the base. Otherwise, you may not have
clear access to the cables when you need to connect them to the main board or
transition board of the InTouch.
Point of entry
Approximate amount of slack after point of
entry
Through the wall into the back
of the InTouch base
• Ethernet cable: 16 in. (40.6 cm) of slack after the
point of entry into the InTouch
• Remote reader cable: 23 in. (58.4 cm)
Through the bottom of the
InTouch base
• Ethernet cable: 6–12 in. (15.2–30.5 cm), depending
on which hole is used
• Remote reader cable: 10 in. (25.4 cm)
• Transformer with 6-ft. cord: 12 in. (30.5 cm)
