Step 5: Install other options
If you purchased one or more of the following options, install them now. These
options connect to the main board on the inside cover of the unit. See the option
installation guides for complete installation instructions. Then return to this guide
to continue the installation.
• Finger scan device (Kronos Touch ID or Kronos Touch ID Plus)
Note: If you are installing the Kronos Touch ID, you must install it and the
Wi-Fi option at the same time. Refer to the Kronos Touch ID installation
guide, before you begin installing the Wi-Fi option.
• Wi-Fi option
• Linear imager option
Step 6: Secure the cables with the strain relief clip
Use the strain relief clip to secure any cables (power cord, PoE, or PoE Plus) that
are routed through the bottom hole of the InTouch. To install the clip, see the
following series of diagrams.
