Chapter 3 Install the Slim Profile InTouch
78
a. Insert screw and clip as shown. Do not fully tighten the screw.
b. Insert the second screw, but do not fully tighten it. Then swivel the clip
over the Ethernet cable.
M3X10 screw
M3X10 screw
