COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S71
9Y3200007CRS0109US0
Name SCV stuck
ISO 14229
P-Code
P0089
J1939-73
SPN 1347
FMI 7
SPN Name
SAE J1939 Table C1
Engine Fuel Feed Pump Pressurizing Assembly #1
DTC Name SCV stuck
Detection item
• SCV stuck at open position (Actual rail pressure continuously exceeds the command rail
pressure)
DTC Set
Preconditions
• Supply pump is normal and pump calibration has been executed
• Engine is operating (Q: 4 mm
3
/st or higher)
• Injector is normal
• Battery voltage is normal
• Sensor supply voltage VCC# is normal
• Rail pressure sensor is normal
DTC set parameter
• Discharge request of supply pump goes below 0 mm
3
/st and the actual rail pressure is
10 MPa (100 kgf/cm
2
, 1400 psi) higher than command pressure
• Above state continues for 26 seconds or more
Time to action or
number of error
detection
• One time or more
Limp Home Action
by engine ECU
(system action)
• Output limitation: Approximately 50 % of normal condition
• Speed limitation (Accelerator limitation: 50 %)
•EGR stop
• Intake throttle 100 % open
Behaviour During
Malfunction
• Insufficient output
• Worsening exhaust gas performance
• Engine stops in some case
Engine Warning
Light
•ON
Recovery from
error
• Key switch turn OFF
Delay time for
recovery
–
Remark • To minimize PM emission
To Next Page
