Kubota 07-CR-E5 User Manual

COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-M16
(2) Normal Value
9Y3200007CRM0016US0
Classifica-
tion
Signal Name Unit
Engine
Stops
During
Start-Up
Idling
During
Accelera-
tion
During
No-load
Maximum
Speed
In-
put
Pulse /
Rotary
signal
Engine speed
min
-1
(rpm)
0
0 → 800
(Ordinary
tempera-
ture)
Approx.
800
(After
warm-up)
Approx.
800 →
2700
Approx.
2700
(After
warm-up)
Engine speed active
flag
– OFF ON ON ON ON
Cam speed active flag – OFF ON ON ON ON
Machine speed km/h When the machine stopped: 0
Analog
signal
Final accelerator pedal
position opening
%0000 → 100 100
Accelerator pedal
position sensor 1
output voltage
V
Sensor unused by CAN input
Accelerator pedal
position sensor 2
output voltage
V
Boost pressure kPa
Approx.
100
Approx.
100
Approx.
100
––
Boost pressure sensor
output voltage
V
Approx.
1.0
Approx.
1.0
Approx.
1.0
––
Fuel temperature °C Representative value:
Approx. 20 °C (68 °F) → Approx. 2.4 V
Representative value:
Approx. 40 °C (104 °F) → Approx. 1.5 V
Fuel temperature
sensor output voltage
V
Coolant temperature °C Representative value:
Approx. 20 °C (68 °F) → Approx. 2.4 V
Representative value:
Approx. 80 °C (176 °F) → Approx. 0.5 V
Coolant temperature
sensor voltage output
V
Intake air temperature °C Representative value:
Approx. 20 °C (68 °F) → Approx. 2.4 V
Representative value:
Approx. 40 °C (104 °F) → Approx. 1.5 V
Intake air temperature
sensor output voltage
V
Atmospheric pressure kPa
Representative value:
Approx. 100 kPa → 3.7 V (Depending on the atmospheric
pressure)
Atmospheric pressure
sensor output voltage
V
Battery voltage V
When stopped: Approx. 12.5 V
When operating: Approx. 14 V
(Depends on the battery charging condition, whether or not
there is a load voltage, rotation speed)
Digital
sig
nal
K
ey Switch –ONONONONON
Start switch – OFF ON OFF OFF OFF
Neutral switch – During neutral: ON
