COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S196
(21) Camshaft Position Sensor (G Sensor) Abnormality (DTC P0340 / 723-8,
P0341 / 723-2)
P0340 / 723-8: No input of G sensor pulse
Behaviour during malfunction (Invalid G signal):
• Engine hesitates at start-up
Detection item:
• Open circuit or short circuit of sensor / harness
• Failure of sensor
DTC set preconditions:
• Battery voltage is normal
• Sensor supply voltage VCC# is normal
• Engine is not stalled
DTC set parameter:
• No recognition of G sensor pulse
Engine warning light:
•ON
Limp home action by engine ECU (system action):
• None
• Engine will stop if both NE and G fail
Recovery from error:
• Diagnostic counter = zero or Key switch turn OFF
9Y3200007CRS0276US0
P0341 / 723-2: G sensor pulse number error
Behaviour during malfunction (Invalid G signal):
• Engine hesitates at start-up
Detection item:
• Open circuit or short circuit of sensor / harness
• Failure of sensor
DTC set preconditions:
• Battery voltage is normal
• Sensor supply voltage VCC# is normal
• Engine speed is 350 min
-1
(rpm) or higher
DTC set parameter:
• Pulse count per rotation is not 5 teeth
Engine warning light:
•ON
Limp home action by engine ECU (system action):
• None
• Engine will stop if both NE and G fail
Recovery from error:
• Diagnostic counter = zero or Key switch turn OFF
9Y3200007CRS0277US0
To Next Page
