Kubota 07-CR-E5 User Manual

COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S307
(65) All Exhaust Gas Temperature Sensor Failure (DTC P3018 / 523599-0)
Behaviour during malfunction:
•None
Detection item:
• All exhaust gas temperature sensor failure simultaneously
DTC set preconditions:
• Engine speed is 1400 min
-1
(rpm) or more
• Quantity of injection is 5 mm
3
/st or more
• Coolant temperature is 50 °C (122 °F) or more: continues longer than 300 sec.
• Passed 100 sec. after cranking
DTC set parameter:
• All exhaust gas temperature sensor failure (sensor low) simultaneously
Engine warning light:
•ON
Limp home action by engine ECU (system action):
• Output limitation: Approximately 75 % of normal condition
Recovery from error:
• Diagnostic counter = zero or Key switch turn OFF
9Y3200007CRS0481US0
1. Check the Installation of Exhaust Gas Temperature sensor
1. Check the installation of all exhaust gas temperature sensors
(T
0
, T
1
and T
2
).
9Y3200007CRS0482US0
2. Check the Exhaust Gas Temperature Sensors (Refer to items
P0543, P0546 and P242C)
1. Check the exhaust gas temperature sensors (T
0
, T
1
and T
2
).
9Y3200007CRS0483US0
OK Go to "2. Check the Exhaust Gas Temperature Sensors (Refer to items
P0543, P0546 and P242C)".
NG Replace the exhaust gas temperature sensor or engine combustion main
parts. (Follow the diagnostic procedure of items P0543, P0546 and
P242C)
(1) Exhaust Gas Temperature
Sensor T
0
(2) Exhaust Gas Temperature
Sensor T
1
(3) Exhaust Gas Temperature
Sensor T
2
(A) Exhaust Inlet Side
(B) Exhaust Outlet Side
OK Normal.
NG Replace the exhaust gas temperature sensor or engine combustion main
parts. (Follow the diagnostic procedure of items P0543, P0546 and
P242C)
(1) Terminal A-GND3
(2) Terminal IDOC, ODOC or ODPF
(a) Exhaust Gas Temperature
Sesnsor (T
0
, T
1
and T
2
)
KiSC issued 03, 2022 A
