Kubota 07-CR-E5 - Monitor Items

COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-M13
[5] AVAILABLE DATA MONITOR SIGNALS (SECURITY LEVEL 2 OR
HIGHER REQUIRED)
(1) Monitor Items
NOTE
• The signals marked with * are inputs from machine ECU through CAN. Terminal names and terminal
numbers have become invalid.
9Y3200007CRM0013US0
Classification Signal Name Unit Terminal Name Terminal No.
Input
Pulse /
Rotary
signal
Engine speed active flag – – –
Cam speed active flag – – –
Engine speed min
-1
(rpm) NE + / − E52 / E72
Machine speed * km/h SPD V14
Analog
signal
Accelerator pedal position % – –
Accelerator pedal position sensor 1
output voltage *
V APS1 V47
Accelerator pedal position sensor 2
output voltage *
V APS2 V67
Boost pressure kPa – –
Boost pressure sensor output
voltage
VPIME67
Fuel temperature °C – –
Fuel temperature sensor output
voltage
VTHFE48
Coolant temperature °C – –
Coolant temperature sensor output
voltage
VTHWE66
Intake air temperature °C – –
Intake air temperature sensor output
voltage
VTHAE47
Atmospheric pressure kPa – –
Atmospheric pressure sensor output
voltage
VPATM–
Battery voltage V +BP
V18,
V38,
V58,
V78
Digital
signal
Key switch – IG-SW V13, V33
Starter switch – STA-SW V12
Neutral switch * – N-SW V30
KiSC issued 03, 2022 A
