COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-M14
9Y3200007CRM0014US0
Classification Signal Name Unit Terminal Name Terminal No.
Output
Basic
control
signal
Final fuel injection quantity mm
3
/st – –
Target rail pressure MPa – –
Actual rail pressure MPa MPa – –
Rail pressure sensor output voltage V PFUEL 1/2 E68 / E49
Target suction control valve (SCV)
current
mA – –
Actual suction control valve (SCV)
current
mA SCV+ / − E09, E29 / E10, E30
Pump learning condition – – –
Pump difference learning correction
value
mA – –
Engine stop flag – – –
Low temperature start mode flag – – –
Registration history (#1 cylinder) – – –
Registration history (#2 cylinder) – – –
Registration history (#3 cylinder) – – –
Registration history (#4 cylinder) – – –
Number of registrations
(#1 cylinder)
–––
Number of registrations
(#2 cylinder)
–––
Number of registrations
(#3 cylinder)
–––
Number of registrations
(#4 cylinder)
–––
Actuator
Exhaust gas recirculation (EGR)
valve target position
%– –
Exhaust gas recirculation (EGR)
valve actual position
%– –
Exhaust gas recirculation (EGR)
position sensor output
––(CAN)
Glow relay – GRLY V24
KiSC issued 03, 2022 A
