COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S195
9. Check the Crankshaft Position Sensor Pull-up Resister
1. Remove the pull-up resister (1 kΩ) which is connected to
harness, then check next item.
• Check if there is improper connection of 1 kΩ resistive
element and connector.
• Check if there is damage of 1 kΩ resistive element.
(measure the resistance of resistive element with tester.)
9Y3200007CRS0275US0
OK Replace the engine ECU and test.
NG Replace 1 kΩ resistive element or improve improper connection.
(1) Resister 1 kΩ 1/4 W
(2) Crankshaft Position Sensor
(3) Camshaft Position Sensor
(4) Rail Pressure Sensor
(5) Intake Air Temperature Sensor
To Next Page
