COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-M5
• The picture shows the pin arrangement of the connector housing viewed from wire side, not mating side.
9Y3200007CRM0005US0
(1) − CAN and EGR
(2) CN221 Engine Joint Connector 3
(3) CN223 EGR Valve
(4) CN226 Resistance Connector (120 Ω)
(5) CN224/225 Can Tool
(6) CN222 Engine Joint Connector 4
(7) − Shield Cable
To Next Page
