COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S185
1. Check the Coolant Temperature Sensor Characteristics for
An Error
1. Refer to DTC P0117, P0118, and check the engine ECU, wiring
harness and sensor for an error.
9Y3200007CRS0252US0
OK Check the cooling system. → Repair the faulty area.
If the cooling system is operating normally, ask the user about
malfunction occurrence based on the freeze-frame data to determine
whether or not the system was used improperly.
NG Check and repair or replace the faulty parts.
(1) CAN1 Connector
(2) Terminal THW
(3) Terminal THW RTN
(a) Pin Assignment
To Next Page
