COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S274
2. Check the DTC
1. Place the key switch to the OFF position first, then return it to
the ON position again.
2. Clear the past DTCs, and check whether the same DTC (P2228
or P2229) is output again or not.
9Y3200007CRS0425US0
Service
specification
OK
OK An electromagnetic interference (EMI) may have caused the temporary
malfunction. There is no problem if the system has recovered.
NG Faulty atmospheric pressure sensor → Replace the engine ECU.
(a) CAN1 Connector
To Next Page
