COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S325
8. Check the High Pressure Piping and CRS Components
(Such as the Fuel Injector and the Supply Pump) for Fuel
Leakage (Engine External Leak)
1. Visually check and specify areas leaking fuel.
2. Be cautious because there may be oil leaks in the high pressure
pipe and injector areas.
9Y3200007CRS0525US0
OK Normal.
NG Repair leaking high pressure pipe, etc. or replace leaking parts.
(1) Rail
(2) Injection Pipe
(3) Supply Pump
To Next Page
