2 Product description
2 Product description
2.1 KUKA.PLC mxAutomation Logix – overview
KUKA.PLC mxAutomation Logix is an add-on technology package with which
a robot can be programmed and controlled via an external PLC (Rockwell con-
troller).
Functions KUKA.PLC mxAutomation Logix offers the following functionalities:
 Function blocks for programming automation tasks with the RSLogix 5000
software
 Teaching of points via status keys on the smartPAD and saving of the
taught points in the PLC
 Sending of messages generated on the smartHMI to an external system
via UDP
Components The following software components are included in the scope of supply of the
software (USB stick):
 KUKA.PLC mxAutomation Logix 1.0
 Function blocks for RSLogix 5000 (Library folder)
 Programming template MxA_Rockwell_Sample.ACD for RSLogix 5000
(Template folder)
 Sample WorkVisual project MxA_Rockwell_Sample.wvs for EtherNet/IP
(Template folder)
Limitations
 KUKA.PLC mxAutomation can be used together with the KUKA.SafeOp-
eration technology package, but not with other technology packages, e.g.
KUKA.GlueTech, KUKA.ConveyorTech, etc.
 Only a KUKA smartPAD may be used as teach pendant for the industrial
robot. External teach pendants are not permissible.
 Only one robot can be controlled via the PLC.
 KUKA.PLC mxAutomation is not approved for the following areas of appli-
cation:
 Medical technology
 Entertainment
 Aerospace industry
 Defense industry
 Nuclear technology
Communication Data exchange between the PLC and the robot controller takes place via Eth-
erNet/IP.
WorkVisual The following software is required for configuring the EtherNet/IP adapter and
mapping the EtherNet/IP signals:
 WorkVisual 2.4 or higher
2.2 Intended use
The online part of KUKA.PLC mxAutomation Logix may only be used on a
KR C4 robot controller with the following software:
 KUKA System Software 8.2
 KR C4 EtherNet/IP 1.1
The offline part of KUKA.PLC mxAutomation Logix is intended for use with
RSLogix 5000 V20 or higher.
