6-14
Parts Lists
PC2R
Front Panel Assembly, N012300070
Left Front Panel Board, N012300080
N053000703 DIODE RECT GP SMT 1A S1A SMA 1N4001 1206 4 D14-15, 17, 22
N053000802 DIODE SWITCH 1N4148 SMT DL-35 2 D13, 21
N054000802 TRANSISTOR MMBT2222L SOT-23 3 Q7, 9, 18
N054002906 TRANSISTOR MMBT2907L SOT-23 4 Q4, 8, 12-13
N054010301 TRANSISTOR NPN KSC2331-Y 2 Q14-15
N055001505 IND FE BD 2.5 TURN SMT 4 L1-4
N059010010 XTL 12.2880MHz +/-50PPM FND PAR 18PF SMT 1 Y1
N061010302 IC LOGIC 74HCU04 SOP14 1 U5
N061014002 IC LOGIC 74HC4051 SOP16-200 1 U11
N063002302 IC OPT COUPLER PC410 SOP6-170 1 U7
N064003508 IC ANA OPAMP DL BIP LO-NOIS NE5532A 1 U9
N064010804 IC LINEAR -12V LM79L12 SOP8 1 VR3
N064010805 IC LINEAR +5V KA78T05 5V 3A TO-220 1 VR1
N064010806 IC LINEAR +12V LM78M12 TO-220 1 VR2
N215000105 SCHOTT TRANSFORMER 67129600 1 L5
N262100608 IC MICROCONTROLLER M37451M8-731FP 1 U1
Part No. Description Qty. Reference Designation
N025323306 MACHINE SCREW BH 3X6 BLK 7 BRACKET CLAMPING PCB & FRONT LEFT & RIGHT
N025383306 MACHINE SCREW FH M3X6 (SMALL) 4 FRONT PANEL & BRACKET CLAMPING PCB
N031063100 BRACKET CLAMPING PCB PC2R 1
N035033900 LCD DISPLAY LEN PC2R 1
N032027426 FRONT PANEL PC2R 1
Part No. Description Qty. Reference Designation
N013035412 CABLE FRONT PANEL PC2R 200mm 1
N041030036 HEADER 16P PICOFLEX MOLEX 90325-0016 1 J603
N041034002 HEADER .098" SP 2P (22-03-5025) 1 J604
N043003704 SW TACT SPST 6mmX6mm 160gf ALPS SKHHDA 6 S15-20
N045010111 LED T1 RED HI EFF DIFFUSED LTL-4221 1 D10
N045010610 LED MINI RED/GREEN DIFUSSED T1 DKL-30RGM 5 D11, 13, 15, 17, 19
N035033800 KEYCAP W/LED PC2R 6 @15-20
N051102304 POT 10K 15mmLx6mmD FLAT ELEC 4 R19-22
N035025813 POWER SWITCH VOLUME KNOB PC2R 4 @R19-22
N051101702 RES CF 15Ω 5% 1/8W 1206 2 R17, 18
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 1 C7
N053000802 DIODE SWITCH 1N4148 SMT DL-35 4 D12, 14, 16, 18
N054000802 TRANSISTOR MMBT2222L SOT-23 2 Q9-10
Part No. Description Qty. Reference Designation
