Parts Lists
PC2X
6-11
PC2X
Final Assembly N012000151
Part No. Description Qty. Reference Designation
E207407181 DOUBLE SIDE TAPE 3M(5MMX50M)#4670.01
N013030951 CABLE TIE 13
N013041601 CABLE SLIDER TO FRONT PANEL 8P PC2/X 1
N013041701 CABLE SLIDER TO CONNECTOR BD 7P PC2/X 1
N013041801 CABLE ENGINE TO CONNECTOR BD 10P PC2/X 1
N013041901 CABLE ENGINE TO CONNECTOR BD 5P PC2/X 1
N013042001 CABLE WHEEL TO CONNECTOR BD 6P PC2/X 1
N013042101 CABLE BUTTON BD TO FRONT PANEL 5P PC2/X 1
N013042201 CABLE ENGINE TO CONN BD POWER PC2/X 1
N013042301 CABLE KEYBOARD BASS & TREBLE PC2/X 1
N013042303 CABLE KEYBOARD BASS PC2X 1
N013042401 CABLE FRONT PANEL TO CONNECTOR B/D PC2/X 1
N015047014 FELT (W/ ONE SIDE ADHESIVE) 1TX10X1000 BLK 2
N015048236
FELT 2TX17X1300 BLK KRYBOARD
K2500X/XS/AES
1
N022002703 SPACER PUSH LOCKING 8.0MM TALL 4
N022003714 CABLE CLAMP 14P 1
N022003720 CABLE CLAMP 20P 4
N025224508 TAPPING SCREW-2 BH 3.5X8 WHITE W/WASHER 35
N025226508 TAPPING SCREW-2 BH 3.5X8 BLK W/WASHER 2
N025323312 MACHINE SCREW BH 3X12 BLK 1
N025323408 MACHINE SCREW BH M4X8 BLK 35
N025323410 MACHINE SCREW BH M4X10 BLK 4
N025323414 MACHINE SCREW BH 4X14 BLK 2
N025328310 MACHINE SCREW BH 3X10 BLK W/WASHER 4
N025328610 MACHINE SCREW BH 4X10 W/SFWASHER BLK 8
N032033633 BOTTOM PC2X 1
N032037732 LEFT SUPPORT WALL PC2/X 1
N032037822 RIGHT SUPPORT WALL PC2/X 1
N032038813 CLAMP PCB PC2/X 5
N032038814 BRACKET CLAMPING ENCLOSURE TOP PC2/X 2
N032038815 BRACKET LOCKING ENDCAP PC2/X 2
N032038950 SPACER (BLK) 2
N032059011 PLATE COVER PCB PC2/X 1
N035020711 KNOB ENCODER 1
N035026511 LCD DISPLAY LENS PC-88 1
N039004322 CABLE MOUNT BASE (DAMD-10) 9
N125223408 TAPPING SCREW-2 BH 3X8 BLK (PLASTIC) 4
N032033522 TOP COVER PC2X 1
