Kurzweil PC2 Series User Manual

Parts Lists
PC2R
6-15
Right Front Panel Board, N012300090
Headphone/Volume/Power Switch Board, N012700019
LCD Board, N012103802
Part No. Description Qty. Reference Designation
N041030036 HEADER 16P PICOFLEX MOLEX 90325-0016 1 J602
N041030326 HEADER .1" SP DUAL ROW 26P (057-026-153) 1 J601
N043003704 SW TACT SPST 6mmX6mm 160gf ALPS SKHHDA 14 S1-14
N045010111 LED T1 RED HI EFF DIFFUSED LTL-4221 8 D1-8
N045010610 LED MINI RED/GREEN DIFUSSED T1 DKL-30RGM 1 D9
N051004710 POT 36STEP 2BIT GRAY 1 SP1
N051102303 POT 10K 20mmLX6mmD KNURLED ELEC 1 R1
N052002422 CAP ELECT 470UF 6.3V 3.5mm SP.11mm 2 C1-2
N035033800 KEYCAP W/LED PC2R 9 @S3-8, 10, 11, 12
N035033600 KEYCAP NO LED PC2R 5 @S1, 2, 9, 13, 14
N035034000 KNOB ENCODER PC2R 1 @SP1
N051101702 RES CF 15Ω 5% 1/8W 1206 2 R9, 10
N051101703 RES CF 1Ω 5% 1/8W 1206 1 R2
N051101757 RES CF 10KΩ 5% 1/8W 1206 12 R3-8, 11-16
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 7 C3-6, 8-10
N054000802 TRANSISTOR MMBT2222L SOT-23 2 Q1, 2
N054002906 TRANSISTOR MMBT2907L SOT-23 6 Q3-8
N061000302 IC LOGIC 74LS145 SOP16 1 U1
N061014003 IC LOGIC MC74HC541DW SOP-20 1 U3
N061020502 IC 74HC373A OCTAL LATCH SOIC20 1 U2
Part No. Description Qty. Reference Designation
N041021007 HEADPHONE JACK (HTJ-064-05) MARK-XXX 1 J1
N041034110 HEADER 10P 1 ROW .098" SP R/A 1 J2
N251102305 POT 10K LIN PUSH SW PC2R 1 R1
Part No. Description Qty. Reference Designation
N013042502 CABLE ENG TO LCD 14P PC2R 330mm 1
N013042603 CABLE ENG TO LCD BACKLIGHT 2P PC2R 1
N245010320 LCD DISPLAY 20X2 Tinama (TM202JFF6) 1

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
