Diagnostics
Test Results
2-3
At the completion of a test, whether pass or fail, press the Cancel button to exit the test. Press
either the Left of Right cursor button to advance to the next test or another test in the sequence.
At the completion of a test, press the Cancel button to return to the test menu. To exit
diagnostics, turn the power off and on to return to normal operation.
Run Burn-in
Burn-in continuously runs the following sequence of tests.
• ROM
• Read-write
• Sound ROM
• ZRAM
• MIDI
If a PCX-1 Board is installed, the sequence of tests is as follows:
• ROM
• Read-write
• MIDI
• PCX-1 ROM
• PCX-1 read
The LCD displays the test results at the completion of each test. To stop the burn-in process and
view the test results for each test run, press the Cancel button. Use the Left or Right cursor
button to scroll through the results of each test.
To exit Run Burn-in and return to the main menu, press the Cancel button. To exit diagnostics,
turn the power off and on to return to normal operation.
Note: If a PCX-1 Board is installed, you must cycle the power after running the SROM or PCX-1
SROM tests. If you do not cycle the power, some tests may not run properly.
Test Results
The top line of the LCD displays the test name to the left and test result to the right. Additional
information, if any, is displayed on the bottom line of the LCD.
At the completion of an individual test, the LCD displays the test results. An expected result is
Pass, Fail, or Not Run.
If a failure occurs, the LCD displays Fail. To the right of Fail, two characters can be displayed in
parenthesis. These characters indicate the type of failure. If the test fails a (t) is displayed. If a
hardware error occurs an (H) is displayed.
