PC2R Disassembly/Assembly
Opening the PC2R
Opening the PC2R
Removing the Top Cover
Before you begin disassembly, please be sure that the power is off, and that the AC power
adapter and all other cables are disconnected.
The top cover is secured to the PC2R with seven screws: three on the top, one on each side, and
two on the rear. See Figure 3-1.
Figure 3-1 PC2R top cover
1. Remove the seven screws that secure the top cover.
Figure 3-2 Removing the top cover
2. Refer to Figure 3-2. Slide the top cover back from the Front Panel Assembly to release the
top cover from the bottom enclosure, and place the top cover safely aside to avoid
damage.
Replacing the Top Cover
1. Place the top cover in position and slide it toward the Front Panel Assembly.
2. Install the seven screws that secure the top cover. See Figure 3-1.
