Kurzweil PC2 Series - Pc2;Pc2 X; Front Panel Board, N012400052

Parts Lists
PC2/PC2X
6-5
PC2/PC2X
Front Panel Board, N012400052
Part No. Description Qty. Reference Designation
N032009401 FRONT PANEL PCB SUPPORT BRACKET PC-88 1
N035026011 BUTTON SM W/LED (3GANG) 5
N035026012 BUTTON SM W/LED RED PC2/X 1
N035026101 BUTTON LG W/LED PC-88 13
N035026141 BUTTON LG W/LED (1,2,3,4) PC2/X 1
N035026142 BUTTON LG W/LED (5,6,7,8) PC2/X 1
N035026143 BUTTON LG W/LED (9,10,11,12) PC2/X 1
N035026144 BUTTON LG W/LED (13,14,15,16) PC2/X 1
N035026145 BUTTON LG NO LED(3) (1,2,3) PC2/X 1
N035026146 BUTTON LG NO LED(3) (4,5,6) PC2/X 1
N035026147 BUTTON LG NO LED(3) (7,8,9) PC2/X 1
N035026148 BUTTON LG NO LED(3) (+/-,0,CLEAR) 1
N035026149 BUTTON LG NO LED(1) (CANCEL) PC2/X 1
N035026150 BUTTON LG NO LED(1) (ENTER) PC2/X 1
N035026151 BUTTON LG W/LED (SOLO) PC2/X 1
N035026152 BUTTON LG W/LED (EQ) PC2/X 1
N035026153 BUTTON LG W/LED (SW1) PC2/X 1
N035026154 BUTTON LG W/LED (SW2) PC2/X 1
N035026155 BUTTON LG W/LED (SW3) PC2/X 1
N035026156 BUTTON LG W/LED (SW4) PC2/X 1
N035026157 BUTTON LG W/LED (SW5) PC2/X 1
N035026217 BUTTON LG NO LED 6
N035026611 LCD SUPPORT BEZEL 1
N035026711 SPIN KNOB BEZEL 1
N041031220 HEADER .1” SP DUAL ROW 20P 1 J604
N041032205 CONN WIRE TRAP 2.00mmSP 5P R/A 1 J701
N041032305 CONN WIRE TRAP 2.00mmSP 5P R/A 1 J601
N041032308 CONN WIRE TRAP 2.00mmSP 8P 1 J602
N043003703 SWITCH TACT SPST 6mmX6mm 160GF 72 S1-72
N044010501 ENCODER 36 STEP 2BIT 1 SP1
N045010111 LED T1 RED HI EFF DIFFUSED LTL-422 49
D1-7, 9-12, 14-16, 20-24, 26-29, 32, 34-38, 40, 42-44, 48, 50-53, 55-60,
63, 66-69
N045010612 LED MINI GREEN DIFUSSED T1 3 D33, 41, 49
N051005010 RES CF 1Ω 5% 1/8W 1 R8
N051100102 RES CF 15Ω 5% 1/8W 7 R1-7
