PC2R Disassembly/Assembly
Front Panel Assembly
Figure 3-5 Front panel faceplate screw locations
Removing the Right Front Panel Board
1. Remove the Front Panel Assembly, as described on page 3-8. It is not necessary to
disconnect all the cables that connect the Front Panel Assembly boards to boards located
on the bottom enclosure.
2. Remove the cable locking clip and disconnect the flat ribbon cable from J601 on the Right
Front Panel Board.
3. Disconnect the flat ribbon cable from J602. This cable uses a picoflex molex connector. To
disconnect it, grip the connector and pull it out straight.
Caution: Do not wiggle the connector back and forth. Doing so, could cause damage to
the header.
Note: Be aware of the marking (red or black) on the cable that indicates the connection to
Pin 1; you’ll need to reconnect the marked edge of the cable to Pin 1 when you replace the
board.
4. It is not necessary to remove the front panel faceplate to remove the Right Front Panel
Board. Two of the screws that secure the front panel faceplate to the Front Panel Assembly
are located above the Right Front Panel Board. Refer to Figure 3-5 and remove the two
screws.
5. Remove the three screws that secure the Right Front Panel Board to the mounting bracket,
and remove the Right Front Panel Board.
Right Front
Panel Board
LCD
Board
Left Front
Panel Board
Headphone/Volume
/
Power Switch Board
faceplate screws

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
