1-2
Introduction
PC2/PC2X
PC2/PC2X
PC2/PC2X Rear Panel
Figure 1-1 PC2 rear panel features
Rear Panel Features
Power Switch—Rocker switch to turn the power on and off.
Power Connector—Keyed four-pin connector to attach the Kurzweil 9VDC power adapter.
MIDI Select Switch—Slide switch to select the operation of the MIDI Thru/Out port. This
switch is recessed into the rear panel so that it cannot be accidentally changed.
MIDI Ports—In, Thru/Out, and Out ports to connect the PC2 to other MIDI devices to receive,
pass, and send MIDI data.
LCD Contrast—Rotary potentiometer to adjust the LCD for the best visibility.
Digital Out—RCA jack to connect to digital recorders and mixers.
Switch Pedals—Three 1/4” jacks to connect switch pedals that can be assigned to control
operations such as sustain, sostenuto, etc. (use 1/4” tip/sleeve).
Continuous Control Pedals—Two 1/4” jacks to connect pedals that can be assigned to control
operations such as volume, expression, etc. (use 10KΩ linear taper potentiometer, 1/4”
tip/ring/sleeve).
Breath Input—A 3.5mm jack to connect a standard breath controller.
Ribbon Input—Modular jack to connect the Kurzweil Ribbon Controller option.
Audio Outs—Balanced 1/4” left and right audio output jacks to connect to an amplifier, mixer
or sound system.
Headphones—Standard 1/4” jack to connect headphones.
Thru / Out
Thru / Out
In
Digital
Contrast
LCD
Out
Switch
Out
1
Continuous
132
Breath
2 Right
Ribbon
Left Headphones
Power MIDI Pedals Inputs Audio Outs
I / 0
Adapter In
9.0V 2.0A
14.0V~0.25A
Switch
Pedals
LCD
Contrast
MIDI
Ports
MIDI
Select Switch
Breath
Input
Digital
Out
Audio
Outs
Continuous
Control
Pedals
Headphones
Power
Connector
Power
Switch
Ribbon
Input
