Kurzweil PC2 Series User Manual

6-8
Parts Lists
PC2/PC2X
LCD Board, N012103800
Pitch & Mod Wheel Assembly, N012300053
Part No. Description Qty. Reference Designation
N013040112 CABLE ENGINE TO LCD 14P RIBBON 1
N013042601 CABLE ENGINE TO LCD BACKLIGHT 2P PC2/X 1
N045010302 LCD UC-20212BLANO SAMSUNG PC-88/MX 1
Part No. Description Qty. Reference Designation
N013040122 CABLE POT TO WHEEL BD 3P #26 AWG 4 2
N041030007 HEADER 0.1” SP 4P (22-03-2041) 2 J202, 203
N041032306 CONN WIRE TRAP 2.00mmSP 6P (52147-0610) 1 J201
N051100118 RES CF 220Ω 5% 1/8W 2 R18, 19
N051100132 RES CF 1KΩ 5% 1/8W 1 R17
N051100310 RES MF 1KΩ 1% 1/8W 1 R12
N051100316 RES MF 1.5KΩ 1% 1/8W 1 R13
N051100336 RES MF 4.99KΩ 1% 1/8W 2 R16, 20
N051100354 RES MF 10KΩ 1% 1/8W 2 R9, 10
N051100379 RES 110K 1/8W 1% 2 R6, 7
N051100439 RES MF 30.1KΩ 1% 1/8W 3 R4, 5, 8
N051100850 RES MF 2.49KΩ 1% 1/8W 1 R11
N051101401 RES POT 100K 3/4 TURN 2 R14, 15
N051101410 RES TRIMPOT 50K 3/4 TURN 1 R3
N051102301 POT ROTARY 10K (K2000) 2 R1, 2
N052001204 CAP CER MONO Z5U .1UF 50V 20% .3AX 6 C1-6
N064001903 IC LINEAR OPAMP TLC2272CP DIP8 3 U1-3
N025223410 TAPPING SCREW-2 BH 3X10 BLK 1
N025224414 TAPPING SCREW-2 BH 3X14 BLK 2
N031053800 BRACKET MOUNTING PITCH & MOD WHEEL PC2 1
N032021811 BUSHING 8.0X26 K2000 1
N032021911 SPRING TORSION MUSIC WIRE 1
N035020311 PITCH & MOD WHEEL 35 2
N035027013 PITCH & MOD WHEEL CHEEK 1

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
