Kurzweil PC2 Series User Manual

Parts Lists
PC2/PC2X
6-7
N051101721 RES CF 270Ω 5% 1/8W 1206 2 R6, 83
N051101724 RES 470 5% 1/8W 1206 2 R18, 117
N051101730 RES CF 1.0KΩ 5% 1/8W 1206 3 R87, 120, 148
N051101734 RES TF 1.5KΩ 5% 1/8W 1206 1 R82
N051101738 RES CF 2.2KΩ 5% 1/8W 1206 2 R8, 66
N051101760 RES CF 20KΩ 5% 1/8W 1206 1 R80
N051101768 RES TF 680KΩ 5% 1/8W 1206 3 R76, 78, 79
N051101780 RES CF 100KΩ 5% 1/8W 1206 7 R7, 15, 88-91, 150
N051101783 RES TF 200KΩ 5% 1/8W 1206 1 R145
N051101790 RES CF 1.0MΩ 5% 1/8W 1206 5 R11, 16, 71, 72, 119
N051101794 RES CF 1.5MΩ 5% 1/8W 1206 1 R63
N051102302 POT R/A 10K 12RV03 (JUNG POONG) 1 R107
N051103073 RES CF 165KΩ 1% 1/8W 1206 1 R64
N051103121 RES TF 121KΩ 1% 1/8W 1206 1 R67
N051103151 RES TF 15.00KΩ 1% 1/8W 1206 8 R122, 123, 132, 133, 135, 136, 138, 142
N051120030 RES TF 3.0KΩ 5% 1/8W 1206 3 R106, 127, 129
N051125201 RES TF 200Ω 1% 1/4W 1210 4 R124, 130, 139, 141
N052001223 CAP CER MONO 0.22UF 50V 20% AX 1 C39
N052001712 CAP ELECT 1000UF 25V RAD 1 C30
N052002412 CAP ELECT 470UF 25V 20% .2SP 1 C31
N052007401 CAP CER NPO 100PF 50V 5% 1206 2 C46, 55
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 21 C12, 13, 23, 24, 29, 32, 33, 35, 38, 41, 42, 44, 45, 48-54, 56
N052007810 CAP CER X7R 1000PF 50V 10% 0603 21 C1-3, 6, 8-11, 14-22, 25-27, 47
N052007833 CAP CER NPO 33PF 50V 5% 0603 2 C4, 5
N052901601 CAP ELECT GP 100UF 16V 20% SZC SMT 4 C28, 34, 36, 37
N052901602 CAP ELECT GP 0.197” SP RAD 1000UF 16V 20% 1 C40
N052901610 CAP ELECT GP 10UF 16V 20% SZB SMT 1 C7
N053000703 DIODE RECT GP SMT 1A S1A SMA 1N4001 1206 5 D12, 14, 15, 17, 22
N053000802 DIODE SWITCH 1N4148 SMT DL-35 14 D1-11, 13, 16, 21
N054000802 TRANSISTOR MMBT2222L SOT-23 4 Q2, 7, 9, 18
N054002906 TRANSISTOR MMBT2907L SOT-23 6 Q1, 3, 4, 8, 12, 13
N054010301 TRANSISTOR NPN KSC2331-Y 2 Q14, 15
N055001505 IND FE BD 2.5-TURN SMT 2 L3, 4
N055001509 IND FE BD SMT 200mA 600Ω 100MHz 0805 2 L1, 2
N059010010 XTL 12.2880MHz +/-50PPM FND PAR 18PF SMT 1 Y1
N061010302 IC LOGIC 74HCU04 SOP14 1 U5
N061014002 IC LOGIC 74HC4051 SOP16-200 1 U11
N061014003 IC LOGIC MC74HC541DW SOP-20 1 U2
N063002302 IC OPT COUPLER PC410 1 U7
N064001602 IC LINEAR OPAMP TL072 SOP8-160 1 U3
N064003508 IC ANA OPAMP DL BIP LO-NOIS NE5532A 1 U9
N064010031 IC COMPARATOR QUAD LM339 SOIC14/14W 1 U4
N064010804 IC LINEAR -12V LM79L12 SOP8 1 VR3
N064010805 IC LINEAR +5V KA78T05 5V 3A TO-220 1 VR1
N064010806 IC LINEAR +12V LM78M12 TO-220 1 VR2
N215000105 SCHOTT TRANSFORMER 67129600 1 L5
N262100608 IC MICROCONTROLLER M37451M8-731FP 1 U1
Part No. Description Qty. Reference Designation

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
